PVC Geomembrane
Introduction:
PVC liners are a geosynthetic containment sheet solution to protect potable water resources and aquatic life from harmful leaching of plasticizers or chemicals. PVC non-reinforced geomembranes were developed for applications such as landfills, canals, ponds and other containment purposes. They are formulated to withstand atmospheric pollutants and chemicals commonly found in industrial settings. PVC is available in thicknesses of 20, 30, and 40 mil, typically in gray but also in black. Some versions are UV stable and fish-friendly; consult your GEOPro for details. It should be covered with 1 foot of clean fill, and the slope must not exceed a 3:1 ratio.
Feature:
Flexibility
PVC geomembranes can conform to irregular surfaces, making them ideal for applications involving uneven terrains.
Durability
They are resistant to UV radiation, chemicals, and environmental stress, ensuring long-term performance.
Low Permeability
PVC geomembranes provide excellent impermeability, effectively containing fluids and preventing seepage.
Cost-Effective
Compared to other liner materials, PVC geomembranes offer a cost-efficient solution without compromising quality.
Ease of Installation
Lightweight and flexible, these liners are simple to transport and install, reducing labor and time costs.
Parameter:
| Item | Values |
| Name | 0.4mm PVC Geomembrane |
| Color | Black or Customized |
| Dimensional stability | Width ±3cmThickness ±0.02mmLength ±10cm |
| Tensile Strength | longitudinal direction 4000n/m ±15% |
| transversal direction 4000n/m ±15% | |
| PHR Level | 50 |
| Unit Weight | 580g/㎡ |
| Visual appearance | No dirt, no contamination, no visible defectives. |
| Printability(visual check): | No scratch no white dots no strips etc. |
| Application temperature | -25℃-70℃ |
| Dimensional Stability | Roll width(m) : 1~13mRoll length(m) : 50~200m |
Application:
PVC geomembranes are used across diverse industries due to their versatility. Some common applications include:
1. Environmental Protection
Landfill Liners: Prevent leachate from contaminating groundwater.
Capping Systems: Seal waste in landfills, reducing odor and methane emissions.
2. Water Resource Management
Pond Liners: Maintain water levels in decorative, agricultural, and industrial ponds.
Reservoirs: Store drinking water or irrigation supplies safely.
Canals: Minimize water loss through seepage.
3. Mining and Energy
Heap Leach Pads: Contain chemicals used in mineral extraction processes.
Secondary Containment Systems: Prevent spills of hazardous materials like oil or chemicals.
4. Agriculture
Manure Pits: Contain livestock waste, reducing environmental contamination.
Aquaculture: Provide a clean and controlled environment for fish farming.
Production Line:
Test Machine:
Warehouse:
Shippment:
Customer Visit:
